Unigraphics Tutorial – Know UGS Swept Operation, Create UG NX6 Swept Feature, Learn UG Sweep

Swept is a type of sweep operation in UG. This Unigraphics NX 6 tutorial will explain the procedure for creating a UGS swept feature. We will discuss the UG swept operation with an example here. The Unigraphics swept operation will enable you to create a tubular kind of feature with different cross sections and guide curves. The Unigraphics tutorial explains the overall procedure for creating the swept feature in UG NX6 however you need practice to become perfect on it. Using sweep operation you can create a tubular kind of feature with any cross section. So, if you need to create an “S” shaped I-beam model or something similar to that you should think of using sweep operation in UG.
