Jigs and Fixtures - Applications and Difference Between Jigs and Fixture

Often the word jig and fixture are used in place of each other. This article will explain about the places where the jigs are used and where the fixtures are used. Also, you will come to know the differences between the jigs and the fixtures. In simple terms, a jig is a tool that guides the cutting (or machining) tool. The most common type of jig is the drill jig, which guides the drill bit for creating holes at desired locations. Using of drill jigs increases production rate drastically by eliminating the time spent using a square scriber, height gauge, center punch, etc.The fixture is the tool which holds the work piece with the machine bed precisely at the desired location.
